Finding the right solution: an overview of our measurement and control technology
Our complete range of measurement and control technology
EASYPRO
The central components of the EASYPRO water sampling stations
Our water sampling stations set new standards in the monitoring and control of liquid processes. Each model is based on a carefully developed base plate, equipped with a variety of specific components. These components are precisely selected to ensure optimum functionality and performance in various industrial applications. Components of the EASYPRO
Base plate
TOPAX® MC single/multi-channel controller or TOPAX® L single-channel controller
Measuring cells and measuring cell fittings
Sample water filter
Flow monitor
DFR 45 flow controller with sample water tapping point and built-in temperature sensor
Inlet and outlet tap
Holder for buffer solutions for adjusting the measuring cells
Multicoloured LEDs
Possible measurement inputs of the industrial water sampling stations
Peracetic acid
Bromine
Free chlorine
Chlorine dioxide
Total chlorine
Conductivity
ozone
Turbidity
Dissolved oxygen
pH value
Redox value
Chlorite
Hydrogen peroxide
Temperature
Discover the EASYPRO water sampling station models
With the EASYPRO, you get a fully customised system for monitoring and controlling various water parameters in your industrial installation. The TOPAX® single or multi-channel controller installed on the EASYPRO continuously measures the water parameters and keeps them within the target range. It offers the option of controlling a large number of actuators and final control elements and is characterised by its very simple and intuitive operation. The multi-coloured LEDs provide a visual warning if the water parameters leave the setpoint range. LED illumination of the fittings
Monitoring and control of various water parameters
Continuous recording of water parameters
with cover (optional)
Compact design
including TOPAX® MC single/multi-channel controller or TOPAX® L single-channel controller
Individually configurable system thanks to modular design
Low water consumption
Plug-in system for water connections
EASYCON GW
A versatile partner
To protect people and the environment, the operation of systems with hazardous gases is associated with the fulfilment of high safety requirements. Monitoring of the room air by means of gas warning devices, in which the increased concentration of gases is registered in the shortest possible time and an alarm is triggered if alarm thresholds are exceeded.
Typical applications for such gas detectors are chlorine gas rooms in swimming pools or waterworks, as well as industrial installations containing ozone and other hazardous gases.
Features & advantages
For use with chlorine gas, chlorine dioxide and ozone
Compact wall-mounted housing
Up to 4 sensors and up to 4 additional temperature sensors
Two freely adjustable alarm thresholds per alarm sensor
3 - 9 potential-free relay outputs
4 analogue outputs 0/4 - 20 mA
Large colour touch display
Data storage on a USB stick
TOPAX
Your versatile partner in measurement and control technologyWithits modular design, the multi-channel controller proves to be an adaptable and extremely competent companion for various measurement and control tasks. The modularity of the multi-channel controller makes it possible to record a wide range of measurement parameters such as chlorine, pH value, redox value or even quadruple pH value measurements in any conceivable combination,and the outputs are also freely selectable. Dosing pumps can be controlled via optocouplers or relays, as well as actuators via relays or a 20 mA output.The colour display with a very high resolution shows a user-friendly user interface. The user-friendliness is rounded off by simple touch operation and multilingual, intuitive menu navigation.Free digital outputs can be configured as required. Regardless of whether they are to switch in the event of low sample water, measured value overflow, measured value underflow or other possible alarm triggers: There are no limits to the configuration.You can use the four analogue outputs (0/4 - 20 mA) or the network capability to forward measured values to a web browser or a remote control station. An adjustable time interval can be used, for example, to automatically remind you to replace sensors due to wear and tear, anddata such as measured values, settings and alarm messages can be easily saved to a USB stick via a USB interface.
Core functions of the multi-channel controller at a glance:
Modular design of the inputs and outputs
Up to four sensors and up to four additional temperature sensors
Freely configurable overviews
Differential value measurement (e.g. ∆pH)
Graphic display of the setpoint deviation
Up to four setpoint sets can be configured and loaded via digital input or timer control
Service entries and sensor changes can be saved
Limit value control (can be used as DIN contact for partial load operation in accordance with DIN 19643)
1 - 9 potential-free relay outputs
Web server and Modbus protocol via Ethernet
Trend display
Large colour touch display
Data storage on a USB stick
TOPAX
Your versatile partner in measurement and control technologyTheTOPAX® MC from Lutz-Jesco represents the pinnacle of innovation in the field of multi-channel controllers. With its modular design, the multi-channel controller proves to be an adaptable and extremely competent companion for various measurement and control tasks. The modularity of the multi-channel controller makes it possible to record a wide range of measurement parameters such as chlorine, pH value, redox value or even quadruple pH value measurements in any conceivable combination,and the outputs can also be freely selected. This means that dosing pumps can be controlled via optocouplers or relays, as well as actuators via relays or a 20 mA output.The colour display with a very high resolution shows a user-friendly user interface. The user-friendliness is rounded off by simple touch operation and multilingual, intuitive menu navigation.Free digital outputs can be configured as required. Regardless of whether they are to switch in the event of low sample water, measured value overflow, measured value underflow or other possible alarm triggers: There are no limits to the configuration.You can use the four analogue outputs (0/4 - 20 mA) or the network capability to forward measured values to a web browser or a remote control station. An adjustable time interval can be used, for example, to automatically remind you to replace sensors due to wear.Data such as measured values, settings and alarm messages can be easily saved to a USB stick via a USB interface.
Core functions of the multi-channel controller at a glance:
Modular design of the inputs and outputs
Up to four sensors and up to four additional temperature sensors
Freely configurable overviews
Differential value measurement (e.g. ∆pH)
Graphic display of the setpoint deviation
Up to four setpoint sets can be configured and loaded via digital input or timer control
Service entries and sensor changes can be saved
Limit value control (can be used as DIN contact for partial load operation in accordance with DIN 19643)
1 - 9 potential-free relay outputs
Web server and Modbus protocol via Ethernet
Trend display
Large colour touch display
Data storage on a USB stick
TOPAX L
Your versatile partner in water treatmentThe TOPAX L single-channel controller monitors the water values present during water treatment and wastewater treatment and controls a dosing system connected for water treatment in real time. In this way, it ensures constant water values in a wide range of applications in compliance with the relevant standards and guidelines. Available in different versions, each model is characterised by specific measurement and control functions, including free chlorine, chlorine dioxide, hydrogen peroxide, pH value, redox potential or conductive conductivity. In addition, the TOPAX® L offers the flexibility to connect various optical and membrane-covered measuring cells.
Features
pH / ORP (redox)
Free chlorine
total chlorine
ozone
peracetic acid
bromine
Turbidity
Flow rate
Conductivity
Chlorine dioxide
Hydrogen peroxide
Chlorite
Dissolved oxygen
Suspended solids
TopView 4
TopView visualisation software
Remote accessOur TOPAX controllers have an optional network interface. With the TopView software, the operator is able to read out and visualise the current measurements and status of each connected TOPAX controller remotely at any time via an RS485 network.
